제품 상세 정보:
|
| Test range: | 0.005—300W/(m*K) | Test mode A: | Room temperature |
|---|---|---|---|
| Test mode B: | RT~120℃ (Required other temp. Control device) | Probe diameter A: | 7.5 mm |
| Probe diameter B: | 15 mm | Resolution: | ±3% |
| Repeatability error: | ≤3% | Test time: | 5~160 sec |
| Power: | AC 220V | External dimension(W*H*D): | 50*41*20 cm |
| Roller Wheel Length: | 460mm | Injection Time: | 0-9999s [Adjustable] |
| Material: | Rubber and Plastic | Dispaly: | Digital |
| Test Fixture: | 5 sets | Transformer Capacity: | 1000VA |
| Usage: | Testing the physical and mechanical properties of rubber and plastic materials | Swing Range: | R300mm |
| Control Temperature: | Within 70±1℃or 100±1℃to room temperature | Ozone Produced Mode: | Ozone generator or UV absorption method |
| Thermal Range: | RT~1000℃ | Load Cell Capacity: | 500N |
| Lamp Size: | Ф31*(450±50)mm | Controlling Accuracy: | ±0.2°C |
| 강조하다: | Thermal Conductivity Tester Laser Flash Method,Thermal Conductivity Tester |
||
This instrument is suitable for measuring the thermal diffusivity and thermal conductivity of high thermal conductivity solid materials, such as metals, graphite, etc., in accordance with the national standard GB/T 22588-2008 "Flash Method for Measuring Thermal Diffusivity or Thermal Conductivity" and ASTM E 1461--2001 "Flash Method for Determining Thermal Diffusivity Test Method".
Technical Parameters
| Item | Parameters |
| Thermal conductivity measurement range | 0.1~2000w/m.k, resolution: 0.1w/m.k |
| Sample size | Φ12×(0.1~5)mm, square=10x10mm, thickness 1~3mm |
| Laser source power | 200W adjustable |
| Test accuracy | ±3% |
| Repeatability | Deviation between two measurements <±3% |
| Testing results | The computer can simultaneously calculate multiple thermal parameters such as thermal diffusion coefficient (thermal conductivity), specific heat capacity, etc. |
| Control mode | Can communicate with general computers, use fully automatic test software, quickly and accurately analyze the test process parameters and output reports for samples |
| Power | 1∮ AC 220V 50HZ 500W |
Why choose us?
1.Design & Production : Solution Consultation for each order
Recommend the most cost -performance machine
Research & Develop the suitable one for Special- designed Model.
2.Shipping & Delivery: One-Stop Service
Production- Deliver to your door - Installation & Training- Technical Support
3.Warranty
1 year warranty with lifetime technology support
4.After-Sale Service
React within 2 Hours
Video inspection & on-site service combined
