Toilet Seat Strength Tester for Cookware Durability Testing

인증
중국 Hai Da Labtester 인증
중국 Hai Da Labtester 인증
고객 검토
그렇습니다 우리는 기계를 지난 주에 받았습니다. 이 기계는 좋, 판매 후 serives를, 이었습니다 아주 직업적 감사합니다.

—— 피터 Maas

회사 대신 당신의 공장과 회사를 방문하기 위해, 기술 직원은 매우 전문적이고 인내심을 가지고 있습니다, 나는 다시 당신과 협력하는 것을 기쁘게 생각합니다.

—— Steve Hubbard

제가 지금 온라인 채팅 해요

Toilet Seat Strength Tester for Cookware Durability Testing

Toilet Seat Strength Tester for Cookware Durability Testing
Toilet Seat Strength Tester for Cookware Durability Testing

큰 이미지 :  Toilet Seat Strength Tester for Cookware Durability Testing

제품 상세 정보:
Place of Origin: China
브랜드 이름: Haida
인증: ISO
Model Number: 5059-HD
결제 및 배송 조건:
Minimum Order Quantity: 1 set
가격: 협상 가능
Packaging Details: each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash,escrow
Supply Ability: 30 Sets per Month

Toilet Seat Strength Tester for Cookware Durability Testing

설명
Gross Weight: 210KG heat source: Ceramic heater
touch screen: LCD Display: LCD screen
Testing Time: Adjustable Reply For Probme: Within 24 hours
Test Parameters: Temperature, pressure, weight, etc. Test Results: Quantitative and qualitative data
Test Methods: Impact, abrasion, chemical resistance, etc. Scale Display: 1 degree
Usage: Testing cookware for durability and safety Leverage Weight: 1KG±0.1KG
Steel Impact Hammer: Having a mass of 1KG ±50g Customized: Welcome
Clamp Strength: 130 + 2.5N Scale Resolution:
Tank Body Matiral: PVC Function: Testing the quality and safety of cookware products
Application: Cookware Industry Test Stroke: 20~66mm
Test Stoke: 20 to 60 mm (adjustable) Fixture: tensile and bend fixture each one
Testing Methods: Impact test, corrosion test, thermal shock test, etc. Applicable Standards: EN ISO 8442-5
강조하다:

High Durability Cookware Toilet Seat Strength Tester

,

cookware Toilet Seat Strength Tester

,

toilet Seat Strength Tester

5059-HD Toilet Seat Ring Strength & Durability Tester
Product Specifications
Attribute Value
Gross Weight 210KG
Heat Source Ceramic heater
Display LCD touch screen
Testing Time Adjustable
Test Parameters Temperature, pressure, weight, etc.
Test Methods Impact, abrasion, chemical resistance, etc.
Leverage Weight 1KG±0.1KG
Steel Impact Hammer 1KG ±50g mass
Clamp Strength 130 + 2.5N
Tank Body Material PVC
Applicable Standards EN ISO 8442-5
Standard Features
Load pressure test range 4000N
Load pressure test accuracy 0.5
Times 999999
Work station 2 Stations
Time display range setting 1s~999999s
Time display accuracy 0.01s
Applications & Test Purpose
Compliant with standards: JC/T 764-2008, T/TZMX001-2017, T/ZZB0147-2016, JG/T 285-2010, GB/T 34549-2017 for dynamic and static strength testing of toilet seats.
Operating Principle
The system uses a programmable logic controller (PLC) as the main controller to manage solenoid valves, pneumatic valves, and cylinders. Pressure sensor data is collected via analog input modules and displayed on the touch screen. Current signal transmission ensures accuracy and reliability even in electromagnetic interference environments.
System Functions
  • Hardware includes acquisition/control systems, HMI, pneumatic systems, and clamping test bench
  • PLC-based control with sensing and speed regulation systems
  • Color LCD touch screen for data display and process control
  • Manual and automatic operation modes
  • Real-time monitoring with alarm functions
  • Power-down data retention capability
Product Images
Toilet Seat Strength Tester for Cookware Durability Testing 0
Toilet Seat Strength Tester for Cookware Durability Testing 1
Toilet Seat Strength Tester for Cookware Durability Testing 2
Toilet Seat Strength Tester for Cookware Durability Testing 3
Customer Testimonials
Toilet Seat Strength Tester for Cookware Durability Testing 4
Toilet Seat Strength Tester for Cookware Durability Testing 5
Why Choose Haida?
  • Design & Production: Custom solutions and R&D for special requirements
  • Shipping & Delivery: Complete one-stop service from production to installation
  • Warranty: 1 year warranty with lifetime technical support
  • After-Sale Service: Rapid response within 2 hours with multiple support options
Frequently Asked Questions
Q: How about your warranty?
A: We offer 1 year warranty with technical support and parts replacement. On-site engineer service is available when necessary.
Q: What is the order process?
A: Inquiry → Quotation → Requirements confirmation → Order → Payment → Production → Testing → Packing → Documentation → Delivery → Installation → After-sales service.
Q: Can we visit your factory before order?
A: Yes, we welcome factory visits and can assist with travel arrangements.
Q: Do you accept customization service?
A: Yes, we provide both standard and customized machines tailored to specific requirements.
About Haida International Equipment
Established in 2004 in Dongguan, China, Haida specializes in R&D and production of material testing equipment. With our own R&D center and four production lines (textile, footwear, leather, mask), we've been serving international markets since 2006.
