Digital Pendulum Impact Tester for Film and Paper Packaging

Digital Pendulum Impact Tester for Film and Paper Packaging
Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging

큰 이미지 :  Digital Pendulum Impact Tester for Film and Paper Packaging

제품 상세 정보:
원래 장소: 중국
브랜드 이름: Haida
인증: CE、ISO
모델 번호: 5086-HD
결제 및 배송 조건:
최소 주문 수량: 1 세트
가격: 협상 가능
포장 세부 사항: 각 세트는 수지 섬유와 PP 필름으로 보호된 다음 작업 담당자와 함께 강한 나무 케이스에 넣습니다.
배달 시간: 명령 뒤에 있는 20 일은 확인했습니다
지불 조건: L/C, D/A, D/P, T/T, Western Union, MoneyGram
공급 능력: 달 당 300개 세트

Digital Pendulum Impact Tester for Film and Paper Packaging

설명
기능: 압축 테스트, 종이 튜브 압축 강도 테스트, 버스트 테스터, 인장 테스트, 종이 테스트 기기 이름: 종이 컵 튜브 압축 강도 테스터, 종이 테스트 기기 종이 GSM 테스터/ 파열 강도 테스터, 종이 테스트 기기
표시하다: LCD, 디지털 디스플레이 장치 스위치: KGF, n. (선택 사항), LBF
강철 볼: 16mm * 20 주파수 범위: 60-300 라운드/분 조절 가능
드라이브 모드: 동력 구동 지림분법: 디지털
시험 스페이스: 600 × 800 × 800mm (사용자 정의 가능) 드롭 높이 범위: 400-1500mm
차원: 530 (l)* 490 (d)* 960 (h) mm 측정 범위: 0~199
맞춤형 지원: OEM ODM 눈물 길이: 43 밀리미터
테스트 영역: 7.3 cm² 작동 모드: PC
드롭 높이: 400~1300 밀리미터 리프팅 속도: 50-300mm/분, 고정 속도 설정
테스트 항목: 파열 강도, 압축 강도, 찢어짐 강도, 펑크 저항, 마찰 계수 등 정확성: 읽기 값의 ± 0.5%
정도: ≤0.5%
강조하다:

Film Paper Packaging Tester

,

Digital Pendulum Impact Tester

EQUIPMENT DETAILS FOR 5086- HD FILM PENDULUM IMPACT TESTER
Product Specifications
Attribute Value
Function Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument
Display LCD, Digital display
Units switch Kgf, N. (Optional), Lbf
Steel Ball 16mm * 20
Frequency Range 60-300 round/min adjustable
Drive Mode Power-driven
Test Space 600×800×800mm (can be customized)
Drop Height Range 400-1500mm
Dimension 530(L)*490(D)*960(H)mm
Measurement Range 0~199
Customized Support OEM ODM
Tear Length 43mm
Test Area 7.3 cm²
Operation Mode PC
Lifting Speed 50-300mm/min, set fixed speed
Test Items Bursting strength, compression strength, tearing strength, puncture resistance, friction coefficient, etc.
Accuracy ±0.5% of reading value
Precision ≤0.5%
Product Description
The 5086-HD Film Pendulum Impact Tester uses a standard pendulum head and weighted pendulum arm to measure impact resistance of plastic films, sheets, and composite films. It evaluates impact toughness for materials including PE/PP composite films, aluminized films, aluminum-plastic composites, nylon films, and materials used in food/medicine packaging. Also suitable for testing pendulum impact resistance of paper and paperboard products.
Testing Principle
The instrument uses a semi-spherical punch to impact and break samples at controlled speeds, measuring the energy consumed during impact. This energy measurement provides the anti-pendulum impact energy value for film samples.
Design Standards
Complies with GB/T8809 and ASTM D3420 standards.
Technical Parameters
Item Description
Capacity 3J
Scale value 0.01J
Pendulum swing radius R280 mm
Pendulum angle 90°
Impact speed 2.5m/S
Impact head size Φ12.7 mm
Sample holder diameter Φ60, Φ89mm
Sample size 100 X 100 mm
Dimensions 780 X 250 X 600 mm
Weight 35kg
Digital Pendulum Impact Tester for Film and Paper Packaging 0 Digital Pendulum Impact Tester for Film and Paper Packaging 1 Digital Pendulum Impact Tester for Film and Paper Packaging 2
About Haida
Haida products serve diverse industries including paper goods, packaging, printing, adhesives, textiles, footwear, leather, environmental materials, toys, hardware, electronics, plastics, and rubber. Our testing equipment meets UL, ASTM, JIS, GB, and ISO standards and is widely used by research institutions, quality inspection agencies, and academic facilities.
