제품 상세 정보:
|
| 싸인 힘 (성수기): | 30KN | 충격력(피크): | 60KN |
|---|---|---|---|
| 주파수 범위: | 5~2,600Hz | 변위(연속): | 100 밀리미터 |
| 맥스. 속도: | 1.8 초당 미터 | Max. Acceleration: | 75 G |
| 1번째 명령 공진 진동수: | 2,400 Hz | ||
| 강조하다: | Sine Wave Vibration Shaker Table,30KN Sine Wave Vibration Shaker,Structural Testing Sine Wave Vibration Shaker |
||
| Attribute | Value |
|---|---|
| Sine force (peak) | 30KN |
| Shock force (peak) | 60KN |
| Frequency range | 5～2,600 Hz |
| Displacement (continuous) | 100 mm |
| Max. Velocity | 1.8 m/s |
| Max. Acceleration | 75 G |
| 1st order resonant frequency | 2,400 Hz |
Electro-dynamic Vibration Testing Equipment is widely used in defense, aviation, aerospace, communications, electronics, automobiles, and home appliance industries. This system is designed for early fault detection, simulating actual working conditions, and structural strength testing.
| Component | Specifications |
|---|---|
| Shaker (Model# EDM-2000) |
|
| Power Amplifier (Model# VSA-H323A) |
|
| Horizontal Slip Table (Model# 30ST-600M) |
|
| Temperature range | 0-40℃ |
| Humidity range | 0-90% (no condensation) |
| Power requirements | 380V/3ph/50Hz, 40kVA |
| Compressed air pressure | 0.6 Mpa |
