| 유형: | 저장 워터 탱크 | 정확도 등급: | 표준 정확성 |
|---|---|---|---|
| 정확성: | ±15% 이내 | 애플리케이션: | PV |
| 맞춤형 지원: | OEM, ODM | 힘: | 220V 50HZ |
| 보호 등급: | / | 전압: | 220V 전기 장비 |
| 보증: | 1년 | 내부 치수: | 700*700*1200mm |
| 외부 치수: | 1000*1000*1320mm | 맥스 견본 크기: | 300*400*100mm |
| 샘플 리프팅 방법: | 샘플을 위아래로 운반할 수 있는 전기 호이스트 장착 | 시료 중량: | 최대 100kg까지 |
| 힘: | 단상, 220V 50Hz | 테스트 표준: | IEC 60529 - IPX7 |
| Operating Modes | Standby, stop, constant-current (CC) charging/discharging, constant-voltage (CV) charging/discharging, constant-power (CP) charging/discharging, constant-current/constant-voltage (CC/CV) charging/discharging |
|---|---|
| Cut-off Conditions | Voltage, current, time, capacity |
| Input Voltage (High-Voltage Side) | 650Vdc to 720Vdc |
|---|---|
| Input Reverse Polarity Protection | Provided |
| Output Voltage (Low-Voltage Side) | 0Vdc to 5Vdc (Adjustable) |
| Voltage Accuracy (Cell Side) | ±0.02%FS @ 25±5℃ |
| Charging Current | 450mA to 1,200,000mA |
| Current Accuracy (Cell Side) | ±0.04%FS @ 25±5℃ |
| Charging Efficiency | Peak efficiency > 92% |
| Input Voltage (Low-Voltage Side) | 0.5Vdc to 5Vdc, Terminal Voltage |
|---|---|
| Voltage Accuracy (Cell Side) | ±0.02%FS @ 25±5℃ |
| Current Range | 120mA to 450,000mA |
| Current Accuracy (Cell Side) | ±0.04%FS @ 25±5℃ |
| Output Voltage (High-Voltage Side) | 640Vdc to 750Vdc |
| Maximum Output Current | 1,200,000mA |
| Discharging Efficiency | Peak efficiency > 90% |
| Response Time | Current response time 10%~90%FS: < 10ms Charge/discharge current switching time 90%~+90%FS: < 20ms |
|---|---|
| Current Overshoot | < 5%FS 0.5m (with 0.5m power cable length) |
| Ripple | < 1%FS |
| Protection Systems | Over-voltage, under-voltage, over-current, output short-circuit, over-temperature, battery reverse-connection, communication loss, sampling abnormality, power-side fuse protection |
| Negative Voltage Acquisition | Capable of directly acquiring true negative voltage |
| Auxiliary Voltage | Provides auxiliary voltage sampling with accuracy less than 2mV |
| Data Reporting | Process step number and timestamp, battery voltage, terminal voltage, auxiliary voltage, charge/discharge current, capacity, energy, operating status |
| Resolution | Voltage setting: 1mV, Voltage display: 0.1mV, Current setting: 1mA, Current display: 0.1mA |
| ESD Protection | Contact discharge ≥ 6KV, Air discharge ≥ 10KV |
| Communication | CAN2.0, communication baud rate 125K/500K |
| Cooling System | Forced air cooling with intelligent fan speed control |
